Parameters |
Values |
| Capacity | 10,20,50,100kg |
| Rated output | 2.0±10%mV/V |
| Zero Balance | ±0.05mV/V |
| Creep(30min) | ≤0.0166%F.S. |
| Non-linearity | ≤0.0166%F.S. |
| Hysteresis | ≤0.0166%F.S. |
| Repeatability | ≤0.018%F.S. |
|
Input Resistance |
390±5Ω |
| Output Resistance | 350±5Ω |
|
Temp.effect on output
|
0.0175%F.S./10 °C
|
|
Temp.effect on zero
|
0.0125%F.S./10 °C |
| Insulation resistance | ≥5000MΩ/100V(DC) |
| Recommended excitation | 5V |
| Maximum excitation | 20V |
| Compensated Temp Range | -10~40 °C |
| Operating Temp Range | -10~50 °C |
|
Safe Load Limit |
150%F.S.
|
|
Breaking Load |
200%F.S.
|
|
Cable size
|
∅5.4x3000mm
|
|
Weight
|
0.5kg
|
|
Material
|
Stainless steel |
| Max.platform size | 500mm*400mm |
FIBOS Measurement Technology (Changzhou) Co.,Ltd. is a leading manufacturer of force sensors and load cells in China.
Our product range includes force sensors/load cells, measuring amplifiers and indicators, and measurement software.We provide the complete force measurement chain from one source and provide customized force sensors/load cells and force-measurement solutions for various applications.
Our products are used in a wide range of industries: automotive,aerospace, shipbuilding,railway,construction and civil engineering,chemical and foods, industrial measurement and control, industrial automation, industrial robots, internet of things, scale manufacturers, calibration laboratories, universities and research institutes, etc.
With a team of engineers once worked in German professional sensor-manufacturing companies, our products enjoy the reputation of being made in China with German technology.
In 2019, FIBOS company received ISO 9001 certification and all of the force sensors/load cells got CE certification(namely certificate of Electromagnetic Compatibility Directive). In 2021, 8 series of our products got RoHS Certificate.
FIBOS has also obtained lots of patents and computer software copyright registration certificates due to its strong technical Research and Development strength.
FIBOS is located in Wujin high-tech industrial development zone, Changzhou City, Jiangsu Province, China, about 180 kilometers away from Shanghai.
Looking forward to the future, FIBOS will take people-oriented, innovation as the foundation, implement the brand strategy, meet the continuous needs of customers with perfect services.
