Force Measurement Wire Rope Tension Load Cell Static Line Tensiometer for Hoisting Applications

1.0 piece
MOQ
Force Measurement Wire Rope Tension Load Cell Static Line Tensiometer for Hoisting Applications
Features Gallery Product Description Request A Quote
Features
Specifications
Model Number: ZYNK
Type: Load Cell
Usage: Force Measurement
Theory: Resistance
Output: 1.0±0.2mV/V
Description: Load Cell
Capacity: 50N~1000N
Sensitivity (Cn): Load Cell: 1.0±0.2mV/V
Accuracy: 0.5~1%F.S
Input Resistance: 1000±100Ω
Output Resistance: 1000±100Ω
Excitation Voltage: 5~12VDC
Insulation Resistance: 5000MΩ
IP Class: IP67
Material: Stainless Steel
Warranty: 1 Year
Basic Infomation
Model Number: ZYNK
Payment & Shipping Terms
Packaging Details: Neutral packing or according to customers' requirements
Supply Ability: 300 Piece/Pieces per Day
Product Description
From 50N to 1000N (higher capacities on request)
Non-linearity
±0.5~1
%F.S
Repeatability Error
<±0.1
%F.S
Creep Error over 30 min.
<±0.1
%F.S
Rated output
1.0±0.2
mV/V
Zero balance
±1
%F.S
Zero shift after loading
<±0.1
%F.S
Temperature effect on output
<±0.1
%F.S/10℃
Temperature effect on zero
<±0.1
%F.S/10℃
Reference temperature
23
℃
Operating Temperature Range
-30…+70
℃
Storage Temperature Range
-50…+85
℃
Input resistance
1000±100
Ω
Output resistance
1000±100
Ω
Insulation resistance(50V)
5000
MΩ
Recommend excitation voltage
5
V DC
Maximum excitation voltage
15
V DC
Safe load limit
150
%F.S
Ultimate overload
300
%F.S
Cable
3
m
Stainless steel
Cable
Length:3m
Diameter:Φ5mm
Company Profile
Ningbo Zhengyan Technology specializes in the research, development, design and production of various high precision force transducers, load cells, torque sensors for multiple applications over 15 years. The products are for a wide range application, such as weighing systems, force measurement, load limitation, process control, oil and gas industry, chemical industry, food and medical industry and so on. We can help you to solve your problem either with one of the special load cells already in production or by the developing a custom-made product. Designing and developing new quality solutions is our specialty.
1. who are we? We are based in Zhejiang, China, start from 2016,sell to North America(15.00%),Western Europe(20.00%),South America(10.00%),Northern Europe(10.00%),Mid East(10.00%),South Asia(5.00%),Southern Europe(5.00%),Oceania(5.00%),Eastern Europe(10.00%),Eastern Asia(5.00%),Africa(5.00%). There are total about 101-200 people in our office. 2. how can we guarantee quality? Always a pre-production sample before mass production; Always final Inspection before shipment; 3.what can you buy from us? Load Cell,Force transducer,Torque transducer,Load Pin,Weighing Sensor 4. why should you buy from us not from other suppliers? Ningbo Zhengyan Technology Co.,LTD has specialized in the research, development, design and production of various high precision force transducers, load cells, load pins, torque sensors for multiple applications over 15 years. 5. what services can we provide? Accepted Delivery Terms: FOB,CFR,CIF,EXW； Accepted Payment Currency:USD,EUR; Accepted Payment Type: T/T,L/C,PayPal,Western Union,Escrow; Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian.
